Class 70th AWS Ansible Part1 July 21st

What is Ansible?

Multiple servers handling with one server.

Ansible handle the all servers , install the softwares maintain them, it is end to end auto machine tool

Ansible we called Configuration management tool

Configuration :(Software,hardware,os cpu ram..etc)

Management :(Tomcat(install,update,patches,delete))

it came 2014  Maichel dehhan Free and open source, maintained by red hat

We have configure one we can use an number of times

Setup will be complex

                                            Ansible Architecture

Playbook file (code) Server create ,software install ,deploy any application

playbook code in yaml format we called yml, Once you create ansible server(main server) playbook, it will create and manage the servers .One server (worker node)to other server to connect we need SSH

Ansible server has(Inventory file , it has work node ip address to manage)

Practicals

Step1: Create 5 instance,ad above shown, Use the MobaXterm termal, it will help to use muti execution

Same command ,all 5 instance

Mobxterm mutiexec mode window

Ip-10.0.2.53 Ansible main server ,remaint dev1,de

Step2: Give Hostname for server identification

EXECUTE THE BELOW COMMANDS ON ALL 5 SERVERS:

sudo -i

hostnamectl set-hostname ansible/dev-1/dev-2/test-1/test-2

Change the name exclude windows give name

Change all server with name

Step3: in ansible server using sudo user or ansible user to communicate work nodes with SSH connection

First set the password sudo all the servers

Changed root password all servers , even if your knowing root password unable to communicate

other servers ,with ssh security configuration allow permit

Step4:

Give the code vim /etc/ssh/sshd_config enter

Below line 65 Passwordauthentication change no to yes

Line 40 uncomment #Permintrootlogin prohibit-password  remove change to yes

yes

After changed Save !wq, this is service so you need reload using below command

[root@ansible ~]# systemctl restart sshd

[root@ansible ~]# systemctl status sshd

get know your ip address using below command hostname -i

Step5: Below steps are perform only ansible server ,Need python for working for ansible

by default python exist server,if not execute second command

yum install ansible -y

yum install python3 python-pip python-dlevel -y (optional)

[root@ansible ~]# yum install ansible -y

[root@ansible ~]# python3 --version

Python 3.9.23

[root@ansible ~]# ansible --version

ansible [core 2.15.3]

  config file = None

  configured module search path = ['/root/.ansible/plugins/modules', '/usr/share/ansible/plugins/modules']

  ansible python module location = /usr/lib/python3.9/site-packages/ansible

  ansible collection location = /root/.ansible/collections:/usr/share/ansible/collections

  executable location = /usr/bin/ansible

  python version = 3.9.23 (main, Jun 27 2025, 00:00:00) [GCC 11.5.0 20240719 (Red Hat 11.5.0-5)] (/usr/bin/python3.9)

  jinja version = 3.1.4

  libyaml = True

Step6:ansible communicate other server ,need other server ip address in inventory

hosts file is called inventory

[root@ansible]# pwd

/etc/ansible/

[root@ansible ]# vi hosts

[dev]

10.0.2.56

10.0.2.54

[test]

10.0.2.58

10.0.2.55

Step7: Generate the keygen using below command



ssh-keygen -- > enter 4 times

[root@ansible roles]# ssh-keygen

Generating public/private rsa key pair.

Enter file in which to save the key (/root/.ssh/id_rsa):

Enter passphrase (empty for no passphrase):

Enter same passphrase again:

Your identification has been saved in /root/.ssh/id_rsa

Your public key has been saved in /root/.ssh/id_rsa.pub

The key fingerprint is:

SHA256:YMrH1dtBtnV8CaJ/hKtBNcFZXCjxh8gKOMxD+QvuZl0 root@ansible

The key's randomart image is:

+---[RSA 3072]----+

|     ..   .*Oo=oo|

|    +..  .+**=.oo|

|     *+..o.+++ ..|

|   . =o+o ooo..  |

|    + + So.o..   |

|     o . Eo .    |

|    . . ..       |

|     + .         |

|    o            |

+----[SHA256]-----+

Step8:The Key file will store in the below path

[root@ansible .ssh]# pwd

/root/.ssh

[root@ansible .ssh]# ls -lrt

total 12

-rw-------. 1 root root  562 Jul 25 18:33 authorized_keys

-rw-r--r--. 1 root root  566 Jul 25 20:11 id_rsa.pub

-rw-------. 1 root root 2602 Jul 25 20:11 id_rsa

id_rsa.pub (public key)

id_rsa(privatekey)

Step9: These two key file need to store all the remaining work node.

ssh-copy-id root@private ip of dev-1 -- > yes -- > password -- > ssh private ip -- > ctrl d

ssh-copy-id root@private ip of dev-2 -- > yes -- > password -- > ssh private ip -- > ctrl d

ssh-copy-id root@private ip of test-1 -- > yes -- > password -- > ssh private ip -- > ctrl d

ssh-copy-id root@private ip of test-2 -- > yes -- > password -- > ssh private ip -- > ctrl d

Dev1 added Successfully.

ssh-copy-id root@10.0.2.56

[root@ansible .ssh]# ls -rt

authorized_keys  id_rsa.pub  id_rsa  known_hosts

[root@ansible .ssh]# ssh-copy-id root@10.0.2.56

/usr/bin/ssh-copy-id: INFO: Source of key(s) to be installed: "/root/.ssh/id_rsa.pub"

/usr/bin/ssh-copy-id: INFO: attempting to log in with the new key(s), to filter out any that are already installed

/usr/bin/ssh-copy-id: INFO: 1 key(s) remain to be installed -- if you are prompted now it is to install the new keys

root@10.0.2.56's password:

Number of key(s) added: 1

Now try logging into the machine, with:   "ssh 'root@10.0.2.56'"

and check to make sure that only the key(s) you wanted were added.

Dev2 added Successfully.

[root@ansible .ssh]# ssh-copy-id root@10.0.2.54

/usr/bin/ssh-copy-id: INFO: Source of key(s) to be installed: "/root/.ssh/id_rsa.pub"

The authenticity of host '10.0.2.54 (10.0.2.54)' can't be established.

ED25519 key fingerprint is SHA256:2CbNMZYgBXW1ZPvq7Yu5vWIKvqYQpff+S21ct2A+rK8.

This key is not known by any other names

Are you sure you want to continue connecting (yes/no/[fingerprint])? yes

/usr/bin/ssh-copy-id: INFO: attempting to log in with the new key(s), to filter out any that are already installed

/usr/bin/ssh-copy-id: INFO: 1 key(s) remain to be installed -- if you are prompted now it is to install the new keys

root@10.0.2.54's password:

Number of key(s) added: 1

Now try logging into the machine, with:   "ssh 'root@10.0.2.54'"

and check to make sure that only the key(s) you wanted were added.

...remaining all

ssh-copy-id root@10.0.2.58

ssh-copy-id root@10.0.2.55

Step10: You can check and test ansible(main server) to dev and test connected or not using ip address

Connected successfully

[root@ansible .ssh]# ssh 10.0.2.58

   ,     #_

   ~\_  ####_        Amazon Linux 2023

  ~~  \_#####\

  ~~     \###|

  ~~       \#/ ___   https://aws.amazon.com/linux/amazon-linux-2023

   ~~       V~' '->

    ~~~         /

      ~~._.   _/

         _/ _/

       _/m/'

Last failed login: Fri Jul 25 20:44:02 UTC 2025 from 109.120.137.7 on ssh:notty

There were 8 failed login attempts since the last successful login.

[root@test1 ~]#

Dev connected from ansible

.[root@ansible .ssh]# ssh 10.0.2.56

   ,     #_

   ~\_  ####_        Amazon Linux 2023

  ~~  \_#####\

  ~~     \###|

  ~~       \#/ ___   https://aws.amazon.com/linux/amazon-linux-2023

   ~~       V~' '->

    ~~~         /

      ~~._.   _/

         _/ _/

       _/m/'

Last login: Fri Jul 25 20:48:52 2025 from 10.0.2.58

[root@dev1 ~]#

Step11:using below command you need check ansible server communicate all other server or not

Coming Green mean communicated successfully.

Step12: Not we are planning to install Git except ansible ,we have 4 servers

if you give this command ,using argument all , it will install all worker node

[root@ansible ansible]# ansible all -a  "yum install git -y"

As you need all server git installed successfully, we have done only ansible remaining worker node automatically installed

instead of all ,her dev only installed

ansible dev -a "yum install maven -y"

See below screen installed only in dev environment.

1. ADHOC COMMANDS:

these are simple Linux commands.

these are used for temp works.

these commands will be over ridden.

ansible all -a "yum install git -y"

ansible all -a "yum install maven -y"

ansible all -a "mvn --version"

ansible all -a "touch file1"

ansible all -a "touch raham.txt"

ansible all -a "ls"

ansible all -a "yum install httpd -y"

ansible all -a "systemctl status httpd"

ansible all -a "systemctl start httpd"

ansible all -a "useradd raham"

ansible all -a "cat /etc/passwd"

ansible all -a "yum remove git* maven* httpd* -y"

--Thanks

Final day Lambda-Prj

Class 65th AWS Project day 4 July 11th

Final day for AWS Complete Project

Step1: This Git code upload all lambda function and main app.py file

https://github.com/Vakatisubbu/Lambda_prj.git

Step2: Create launch template ,base on the autoscaling and target group creation steps

Name: Launch-template

Step3: Select Quick start

AMI:Amazon Linux (Free tier eligible)

Instance Type: t2.micro(Free tier eligible), Network setting Don't include in launch template

we will do at time of autoscaling

Step4: click Advance detail , add below code user data

#!/bin/bash
# Update system and install dependencies
yum update -y
yum install -y python3 python3-pip git

# Configure Python environment
python3 -m pip install --upgrade pip
python3 -m pip install --user flask requests boto3

# Clone the project
cd /home/ec2-user
git clone https://github.com/Vakatisubbu/Lambda_prj.git

# Set proper permissions (added your requested lines)
sudo chown -R ec2-user:ec2-user /home/ec2-user/Lambda_prj/
sudo chmod 755 /home/ec2-user/Lambda_prj/
cd Lambda_prj

# Create systemd service file
cat << 'EOF' > /etc/systemd/system/digital_library.service
[Unit]
Description=DigitalLibrary Flask App
After=network.target

[Service]
User=ec2-user
Group=ec2-user
WorkingDirectory=/home/ec2-user/Lambda_prj
ExecStart=/usr/bin/python3 app.py
Restart=on-failure
RestartSec=5s
Environment="PATH=/usr/local/bin:/usr/bin:/bin"

# Security hardening
NoNewPrivileges=true
PrivateTmp=true
ProtectSystem=full

[Install]
WantedBy=multi-user.target
EOF

# Enable and start the service
systemctl daemon-reload
systemctl enable digital_library
systemctl start digital_library

Step5: Then click create launch template,created launch template

Step6:select the template and actions>create autoscaling group

Step7:Click next

Step8:Attached new load balancer

Step9:Public subnets new name give to target group Target-group

Step10:No changes,click Next

Step12:Desire give 2, no change Click next ,

Add notification -optional Click next

Add tags -option Click next

Review >Create Autoscaling Group

Step13: Two instance created successfully

Note: Subnet Public ip must automatic enabled

Step14:Create new service Demon service

First Sever

[ec2-user@ip-10-0-2-60 systemd]$ cd /etc/systemd

[ec2-user@ip-10-0-2-60 systemd]$ sudo  vi digital_library.service

[Unit]
Description=DigitalLibrary Flask App
After=network.target

[Service]
User=ec2-user
Group=ec2-user
WorkingDirectory=/home/ec2-user/Lambda_prj
ExecStart=/usr/bin/python3 app.py
Restart=on-failure
RestartSec=5s
Environment="PATH=/usr/local/bin:/usr/bin:/bin"

# Security hardening
NoNewPrivileges=true
PrivateTmp=true
ProtectSystem=full

[Install]
WantedBy=multi-user.target

[ec2-user@ip-10-0-2-60 ~]$ cd /home/ec2-user/Lambda_prj/

[ec2-user@ip-10-0-2-60 ~]$ pip3 install flask

[ec2-user@ip-10-0-2-60 ~]$ pip3 install requests

[ec2-user@ip-10-0-2-60 ~]$ pip3 install boto3

[ec2-user@ip-10-0-2-60 ~]$ cd /home/ec2-user/Lambda_prj/

[ec2-user@ip-10-0-2-60  Lambda_prj ~]$  sudo systemctl daemon-reload

[ec2-user@ip-10-0-2-60  Lambda_prj~]$ sudo systemctl daemon-reexec

[ec2-user@ip-10-0-2-60 Lambda_prj ~]$ sudo systemctl restart digital_library

[ec2-user@ip-10-0-2-60  Lambda_prj~]$ sudo systemctl status digital_library

● digital_library.service - DigitalLibrary Flask App

     Loaded: loaded (/etc/systemd/system/digital_library.service; enabled; preset: disabled)

     Active: active (running) since Thu 2025-07-24 19:07:17 UTC; 5s ago

Second  server:

[ec2-user@ip-10-0-2-13 ~]$ cd /etc/systemd

[Unit]
Description=DigitalLibrary Flask App
After=network.target

[Service]
User=ec2-user
Group=ec2-user
WorkingDirectory=/home/ec2-user/Lambda_prj
ExecStart=/usr/bin/python3 app.py
Restart=on-failure
RestartSec=5s
Environment="PATH=/usr/local/bin:/usr/bin:/bin"

# Security hardening
NoNewPrivileges=true
PrivateTmp=true
ProtectSystem=full

[Install]
WantedBy=multi-user.target

[ec2-user@ip-10-0-2-13 ~]$ cd /home/ec2-user/Lambda_prj/

[ec2-user@ip-10-0-2-13 Lambda_prj]$  sudo systemctl daemon-reload

[ec2-user@ip-10-0-2-13 Lambda_prj]$ sudo systemctl daemon-reexec

[ec2-user@ip-10-0-2-13 Lambda_prj]$ sudo systemctl restart digital_library

[ec2-user@ip-10-0-2-13 Lambda_prj]$ sudo systemctl status digital_library

● digital_library.service - DigitalLibrary Flask App

     Loaded: loaded (/etc/systemd/system/digital_library.service; enabled; preset: disabled)

     Active: active (running) since Thu 2025-07-24 19:07:17 UTC; 5s ago

Step15:Check with public ip's Application working or not,Port in the app.py mentioned 5000



First instance Public ip :13.41.229.236

Second instance Public ip

Step16: If you are facing any issues Try these steps

[ec2-user@ip-10-0-2-13 Lambda_prj]$ sudo chown -R ec2-user:ec2-user /home/ec2-user/Lambda_prj

[ec2-user@ip-10-0-2-13 Lambda_prj]$ sudo chmod 755 /home/ec2-user/Lambda_prj

[ec2-user@ip-10-0-2-13 Lambda_prj]$ sudo systemctl daemon-reload

[ec2-user@ip-10-0-2-13 Lambda_prj]$ sudo systemctl start digital_library

[ec2-user@ip-10-0-2-13 Lambda_prj]$ sudo systemctl enable digital_library

[ec2-user@ip-10-0-2-13 Lambda_prj]$ sudo systemctl restart digital_library

[ec2-user@ip-10-0-2-13 Lambda_prj]$ sudo systemctl status digital_library

Step17: target group /health 5000 override port

Loader balancer and lister 5000 port

Load balancer add the lister 443

Step18:Route 53 you need add the A record,if any existin A record delete , create new for loadbalancer

using dns

Step19:existing load balancer Click a record

Step20:

Step21: it will take some time vakatisubbu.xyz 10 to 15 minute synchrize

Step22: Mean while database i have already created, it was shutdown just restart the database

it is starting

Step23: Lambda functions already , i have created  Below are reference ,

Already ,i have share Git Repo first line of this page ,you take create lambda function accordingly

Step24:Correspondindg Rest API also need create,All are usign Get function

Step25:

All test API's intergration request mapping parameters below

1)

/BarrowBooks

Content type : application/json

{

  "user_id": "$input.params('user_id')",

  "book_id": "$input.params('book_id')"

}

2)

/GetBarrowBooks

Content type : application/json

{

  "user_id": "$input.params('user_id')"

}

3)

/GetBarrowHistory

Content type : application/json

{

  "user_id": "$input.params('user_id')"

}

4) No input parameter  all list of book will populate

/ListBooks

Nothing

5)

/ReturnBooks

Content type : application/json

{

  "user_id": "$input.params('user_id')",

  "book_id": "$input.params('book_id')"

}

6)

/Signin

Content type : application/json

{

  "user_id": "$input.params('user_id')",

  "book_id": "$input.params('book_id')"

}

7)

/Signup

Content type : application/json

{

   "name": "$input.params('name')",

   "mobile": "$input.params('mobile')",

   "email": "$input.params('email')",

   "password":"$input.params('password')",

   "gender": "$input.params('gender')",

   "location":"$input.params('location')",

   "image": "$input.params('image')"

}

8)

/Welcome

Content type : application/json

{

  "user_id": "$input.params('user_id')"

}

Step26:

After database restarted and domain 15minute taking to synchrize, See below webpage login successfully,So Digital Library project completed successfully...

--Thanks

AWS Project day 3

Class 64th AWS Project day 3 July 10th

Create one more lambda function

Step1:Need to create below lambda function

Step2: Layer which common code in all database connection code every lambda function, instead of calling all the connection every function to over the repeated entry need to use layer
Environment variables DB_HOST,DB_NAME,DB_USER,  DB_PASS
If you stared with Signup go to loacal singup folder code install the msql pip install pymysql -t.

Create one python directory whatever move to pymsql and pyMSql ..executable file to python folder

Zip the python folder  python.zip

Step3:Create the layer ,upload the Signup zip file and click create layer

ccit-mysqldb-layer

Step4: Creation of RDS database

Create Mysql steps:

Aurora and RDS> Create database

Single(A-Z) DB instance deployment (1 instance)

DB Instance Identifier  :Digital-library

Credential Settings >Self managed  > admin /admin1234

DB Instance Class >Burstable Classes :db.t4g.micro

Public access :Yes

Click Create database

Step5:

Endpoint :digital-library.c5iyik8mi7ym.eu-west-2.rds.amazonaws.com

User admin

password:admin1234

Database Schema creaion: CREATE DATABASE IF NOT EXISTS digital_library; USE digital_library;

CREATE TABLE IF NOT EXISTS users ( id INT AUTO_INCREMENT PRIMARY KEY, name VARCHAR(100) NOT NULL, mobile VARCHAR(20) NOT NULL, email VARCHAR(100) NOT NULL UNIQUE, password VARCHAR(255) NOT NULL, gender VARCHAR(10), location VARCHAR(100), image VARCHAR(255) );

CREATE TABLE IF NOT EXISTS books ( id INT AUTO_INCREMENT PRIMARY KEY, title VARCHAR(255) NOT NULL, author VARCHAR(255), available BOOLEAN DEFAULT TRUE );

CREATE TABLE IF NOT EXISTS history ( id INT AUTO_INCREMENT PRIMARY KEY, user_id INT, book_id INT, borrow_date DATETIME, return_date DATETIME, FOREIGN KEY (user_id) REFERENCES users(id) ON DELETE CASCADE, FOREIGN KEY (book_id) REFERENCES books(id) ON DELETE CASCADE );

INSERT INTO books (title, author, available) VALUES ('Wings of Fire', 'A.P.J. Abdul Kalam', TRUE), ('The Guide', 'R.K. Narayan', TRUE), ('Godan', 'Munshi Premchand', TRUE), ('Train to Pakistan', 'Khushwant Singh', TRUE), ('Ignited Minds', 'A.P.J. Abdul Kalam', TRUE), ('Mahabharata', 'Ved Vyasa', TRUE), ('Python Crash Course', 'Eric Matthes', TRUE), ('Digital Fortress', 'Dan Brown', TRUE), ('You Can Win', 'Shiv Khera', TRUE), ('Zero to One', 'Peter Thiel', TRUE);

Step6: add environment variabe
Environment variables DB_HOST:digital-library.c5iyik8mi7ym.eu-west-2.rds.amazonaws.com
      ,DB_NAME=digital_library,DB_USER=admin ,DB_PASS=admin1234

Step6: Give Connection details to the lambda function click save

Step7: add Layer

Step8: Select custom layer ,select you layer and version click add

Step9:Every function add the code deploy and add the environment variable all the remaining functions

Step10:

Step11: Create API Gateways

Rest API  Click Build  Click Create API

Step12:Create Resource the API,Signup,select below options Create resource

Step13:Delete the Option methos, create new method for Get method

Step14: Select below option for Signup API choose correspinding lambda function create create method

Step15: Create resouce Signin Click create resource

Step16:Delete the exist Option metho,Click create method for Signin Click

Step17:Need create all resource and create methods.

Step18:Create Deploy API ,after deploy all the url copy from the method,past them in you main

app.py file

Step19:Copy all url from the API,past that into your code

Step20:Modify the exist project code ,like below and execute

Step21: We missed Integration Input parameter adding Signup Click Save

Step22:Signin Integration mapping templated

{

  "email": "$input.params('email')",

  "password": "$input.params('password')"

}

Step23: After changes Click deploy API

Step22:

Step23: Data inserted Successfully

Step24: Every not required upload lambda function runtime file to All lambda function instead of them you just add the layer for the every lambda function

Added the layer customize

 Add same layer similar all database connection lambda function click add

This is the completed Code

--Thanks
